industrial grade hdmi cofdm video transmitter long range oem odm

industrial grade hdmi cofdm video transmitter long range oem odm

  • industrial grade hdmi cofdm video transmitter long range oem odm
industrial grade hdmi cofdm video transmitter long range oem odm
Product Details:
Place of Origin: China
Brand Name: Huanuo
Certification: CE/FCC/ROHS
Model Number: HN-550Plus
Payment & Shipping Terms:
Minimum Order Quantity: 1pcs
Price: Negotiation
Packaging Details: Professional carton box package
Delivery Time: 2~3 working days
Payment Terms: T/T
Supply Ability: 500 pieces per month
Contact Now
Detailed Product Description
Video Input: HDMI And RJ-45 Output Frequency: 2402~2482MHz
Output Power: 37dBm Chanel Bandwidth: 2MHZ/4MHZ/8MHz
Encryption: 128 Bit AES Modulation: TDD-COFDM,QPSK,QAM16,QAM64
Video Encoding: H.264 Weight: 160g
High Light:

COFDM Video Transmitter Long Range


ODM COFDM Video Transmitter


COFDM wireless hd video transmitter

                                                   Industrial Grade HDMI COFDM Video Transmitter Long Range OEM ODM



Product Introduction:


HN-550Plus H.264 TDD_COFDM this product is our company released latest zero-latency H.264 1080P HD wireless transmission equipment,the use of advanced time division processing technology and leading COFDM modulation technology,providing a complete two-way data transmission channel (supports AES_128 encryption), and ultra-low latency (20ms) high-definition video transmission channel,the perfect

realization of real-time,high-speed mobile data,audio and video transmission.




Widely application for UAV system,fire fighting,unmanned equipment,intelligence control and ect.



Product features


● Ultra-low latency (20ms) full HD 1080P video transmission


● Standard RS-232 & RS-485 + RJ45 + Mini HDMI interface


●20Mbps data flow, adaptive dynamic stream allocation technology


●Multiple bandwidth regulation (2MHz/4MHz/8MHz)


●128 bit AES encryption


●Transparent PTP&PMD network transmission technology


●Non line of sight (NLOS), high-speed mobile transmission


● High definition OLED panel digital display,simple interface easy to operation


●Small size, light weight, low power consumption



Technical parameters:


Model HN-550 Plus
Power input DC 7~17V
Power consumption 12V_1.5A (full load maximum output power)



10/100 BaseT,Auto-MDI/X, IEEE 802.3
Video input Mini HDMI interface, RJ-45


Data input

Output frequency

2402MHz-2482MHz,Step 1MHz


Output power

37dBm/5Watt adjustable

RF Antenna interface SMA
Bandwidth 2 MHz /4MHz/8MHz
Encryption 128 bit AES
Correction mechanism 32 bit of CRC,ARQ
Modulation QPSK,QAM16,QAM64
Video encoding H.264
Parameter control By adjusting the parameters of OLED control panel
Dimensions 79mm*52mm*31mm
Weight 160g
